white nature PE1000 UHMWPE rod

UHMWPE Rod

UHMWPE Rod is an excellent engineering plastic that can solve many problems while others cannot. UHMWPE Rod is not as widely known as other engineering plastics such as Nylon Rod but is still very important and helpful than the more common engineering plastics because of its distinct advantages.

Advantages of UHMWPE Rod
UHMWPE Rod takes great advantage of its low co-efficient of friction which means it will produce bearings, pulleys or bushes that are very free running, low friction and long lasting. UHMWPE Rod is also very abrasive resistant, this means that UHMWPE Rod can survive longer than other materials when used in high demand environments such as grit or gravel. UHMWPE Rod can often be used in high demand components in the food industry, this is because it has a very low moisture absorption that gives UHMWPE Rod an FDA approval and means that bearings etc. will not expand due to any moisture absorption. Another reason that UHMWPE Rod is also used in the marine industry for pulleys is its low friction and minimal moisture absorption.


Properties of UHMWPE rod

Special Properties of UHMWPE rods
  • High Abrasion and Wear Resistances

  • Low coefficient of friction

  • High Impact strength

  • Self-lubricating properties

  • No water absorption

  • Excellent performance even at  -200 °C

  • High resistance to corrosion and chemicals

  • Excellent resistance to stress cracks

  • Operating temperature range  -250???C to 80???C

  • Short term max temperature  130???C


Applications of UHMWPE rod

Bottling and Conveying industry

Packing industry

Material Handling

Food industry

Chain and cam guidance

General conveyor technology

Dock Fenders



Sizes

Length: 1000/2000 mm

Diameter: 10 to 250 mm

Cut to size

Machining service

*Note: Custom sizes, diameters available upon request



Colors

White

Red

Black

Green

Blue

Yellow

Grey

Custom
