PE1000 UHMWPE sheet flame retardant

Ultra-high molecular weight polyethylene UHMW-PE / PE 1000 is thermoplastic with high molecular weight (as determined by viscometric method).

PE 1000 / PE-UHMW sheets - Flame Retardant is a Self-extinguishing and Antistatic polyethylene which is highly temperature resistant and is suitable for the Mechanical engineering, Electrical industry, and Packaging industry.

Explosion and flammability are significant risks for all types of industries manufacturing flammable goods and in the coal industry.

It is vitally necessary that the UHMW lining is flame retardant in conveyor belts and bunkers. Depending on the product it is possible to enhance the functional properties of the flame retardant UHMW-PE 1000 by means of additives.

Additives inevitably increase costs, but when considering material lifetime and initial lining effort, the advantages of choosing the right material become apparent. There is no halogen and antimony in the flame retardant UHMW-PE 1000. Smoke absorption is minimum.

Inquire Now Next Product

Featurer of UHMWE sheet

Characteristics:

PE-UHMW sheets have great high impact strength and rigidity;

High corrosion resistance;

PE-UHMW sheets offer excellent chemical resistance;

Very good electrical insulator;

Excellent absorption of vibrations and noise;

Physiologically harmless;

Main Features:

Minimal moisture absorption

High impact strength

Easy to machine

Low friction rate

UHMWPE properties

Mechanical properties;

Yield stress	DIN EN ISO 527	MPa	22
Elongation at break	DIN EN ISO 527	%	>200
Tensile modulus of elasticity	DIN EN ISO 527	MPa	700
Notched impact strength	DIN EN ISO 179	kJ / m2	no break
Shore hardness	DIN EN ISO 868	scale D	63

Thermal properties:

Melting temperature	ISO 11357-3	°C	135
Thermal conductivity	DIN 52612-1	W / (m * K)	0,40
Thermal capacity	DIN 52612	kJ / (kg * K)	1,90
Coefficient of linear thermal expansion	DIN 53752	10-6 / K	150 - 230
Service temperature, long term	Average	°C	-250 … 80
Service temperature, short term (max.)	Average	°C	130
Vicat softening temperature	DIN EN ISO 306, Vicat B	°C	79

Other properties

Density	DIN EN ISO 1183-1	g / cm3	0,99
Water absorption	DIN EN ISO 62	%	<0,05
Flammability (Thickness 3 mm / 6 mm)	UL 94		V0
Molecular weight	-	106 g/mol	~ 9

UHMW-PE Sheets standard size

· 3050*1220mm

· 6050*1820mm

· 3030*1550mm

· 4520*2000mm

· 3050*3050mm

· 2000*1000mm

Type of UHMWPE sheet

· Standard Virgin sheet, Anti-static, Flame-retardant, Glass-filled, Ceramic filled, reprocessed, oil-filled, and other grades.

We are manufacturer of UHMWPE sheet, we own about 30 cnc machines to process the products to satisfy any requirement of customers.
