Ultra high molecular weight polyethylene PE 1000

Inquire Now Next Product

Applications of PE1000 lining sheets

Production of equipment parts subject to mechanical abrasion, increasing their service life.

Lining and lining of units and mechanisms:

Bunkers, chutes and chutes
thickeners, trays
Hoppers, railway cars
Dump truck bodies
Buckets of excavators, dumps of bulldozers,
Silos and containers,
Cargo holds of dry cargo ships (Port construction)
Lining of pallets of blending machines;
Coating of rinks (artificial ice) and hockey rinks (protection of boards from damage)

Standard manufactured dimensions, length x width:

Thickness: 8 - 120 mm

Specifications

Technical properties	Values
material color	Green/White/Black
Molecular weight \| g/mol	5x10^6
Density \| kg/dm3	≤0.93
Water absorption - saturation at 23 C	<0.01
Mechanical properties
Expanded Voltage / Breakdown Voltage \| MPa	~17
Relative Elongation (At Break) \| %	>300
coefficient of elasticity \| MPa /td>	>700
Charpy - impact strength of the sample with a notch - double-sided kJ/m2	≥170
Hardness D \|	61-66
Ball hardness \| N/mm2	>30
Wear Resistance (Sand Slurry Test) \| %	100
Coefficient of friction against steel (0.25m/s, 0.25N/mm2)\| µ	~0.2
Thermophysical Properties
Thermal conductivity at 23 C \| W/(Kxm)	0.4
Linear thermal expansion koeffizent \| α (average between 23 and 60 C \| m/(mx K)	20x10^5
Upper working temperature in air
Short term operating temperature \| C	90
Long-term: within 5000 h \| C	80
Lower Operating Temperature \| C	-200
Records are kept in accordance with UL94 - specimen thickness 3/6 mm	HB
Melting Point \| C	130-135
Electrical Properties
Strength \| kV/mm	≤45
Specific volume electrical resistance \| Ω x cm	>10^14
Surface Resistance \| Ω	>10^13
Physiological Properties
Approved for use in the food industry (FDA)	Yes
Approved for use in the food industry (EU)	Yes
